1-4 ._J 1—i o id o %d 0 jSg§ O 1, h- ib 7o-.ofr … FIGURING A BARN BILL 65 section and the several members of the truss mayreadily be located by reference thereto: 4 pieces 2x 8 —14 studs. 4 pieces 2x10 — 28 purlin posts. 2 pieces 2x12 — 28 chords. 2 pieces 2x10 — 34 cross braces. 2 pieces 2x10 — 5 angle braces. 2 pieces 2x10 — 48 cross braces. 4…
