Illustrated catalogue of galvanized iron roofing and shedding, iron structures, &c. : patent portable steel railways, railway plant, iron bridges, &c. (1884)

A. & J. Main & Co. · A. & J. Main & Co. · leaf 7

An illustration from Illustrated catalogue of galvanized iron roofing and shedding, iron structures, &c. : patent portable steel railways, railway plant, iron bridges, &c., 1884, leaf 7
Eaves Beam, and is adopted where the height and otherarrangements of the structure render them suitable. No. 17 is theirArched Lattice Eaves Beam; and No. 18 is their Arched SkeletonBeam, the advantages of which are, that in Shedding of considerableheight they take a deeper hold upon the Columns,… … VENTILATION OF IRON SHEDDING.

Roofing · Sheet roofing · Corrugated roofing · Sheet metal · Structural iron · Ironwork

Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
