22-8 Fig. 126.—plan or cellar. 178 HOUSE-PLANS FOR EVERYBODY. back from the face of the foundation, to provide a foot-ing for the water-table and brick inclosing. The inside of the exteriorframe is roughlyceiled aroundwith hemlockboards, whichare thoroughlynailed to thestudding, bring-ing them… … PIAZZA. Fig. 127.—PLAN OF FIRST FLOOK, foundation ; B the water-table :inside boarding ;M,M,JB, timber ofthe frame. Thewater - table, ofdressed stone, islaid on the foun-dation in cementmortar. Thebrick are laid instretchers, ingood lime andsand-mortar,with close joints.Anchor nails (Og.130) are…
