The American cottage builder: a series of designs, plans, and specifications, from $200 to $20,000. For homes for the people. Together with warming, ventilation, drainage, painting, and landscape gardening (1854)
Bullock, John · New York, Stringer & Townsend · leaf 206
are of cast-iron, with brick cores, con-nected with wrought-iron tie-rods. 1 and 2, represents the plan of window and door jambs,on alternate courses. 3. Partition block. 4 and 5. Plan of angles, on alternate courses. 6. Square jamb and chimney brick. 1. Section of a one foot and two inch wall. 8.… … THE AMERICAN COTTAGE BUILDER. 1ST
Architecture, Domestic
