The American house-carpenter; a treatise upon architecture, cornices and mouldings, framing, doors, windows, and stairs. Together with the most important principles of practical geometry (1852)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 134
Fig. 160. it cuts a perpendicular drawn from a, as at d; and that will be thecentre of the curve. In a similar manner, the centres are foundfor the mouldings at Fig. 147, 151, 153, 156, 157, 158 and 159.The centres for the curves at Fig. 160 and 161, are found thus:bisect the line, a 6, at c ; upon…
Carpentry · Architecture
