Fig. 94. and their strength must be calculated accordingly. (SeeArts, yo to 80 and 214 to 222.) If the dome is large and ofimportance, two other trusses may be introduced at rightangles to the foregoing, the tie-beams being preserved in … Fig. 95. one continuous length by framing them high enough to passover the others. 236.—Ribbed Dome.—When the interior must be keptfree, then the framing may be composed of a succession ofribs standing upon a continuous circular curb of timber, as 2l8 CONSTRUCTION. seen at Figs. 95 and 96—the…
