ose stream is rapid, or where it is ne-cessary to preserve an uninterrupted passage for the purposes ofnavigation, the centre must be constructed without intermediatesupports, and without a continued horizontal tie at the base ; sucha centre is shown at Fig. 233. In laying the stones from thebase… … Fig. 233. additional security. Upon this plan, with some variation to suitcircumstances, centres may be constructed for any span usual instone-bridge building. 324.—In bridge centres, the principal timbers should abut, andnot be intercepted by a suspension or radial piece between.These should be in…
