The American house-carpenter; a treatise on the art of building, and the strength of materials (1867)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 103
of the cross-beamswhich rest upon the architrave, the triglyphs; the tree laid onthe cross-beams as a support for the ends of the rafters, thebed-moulding of the cornice; the ends of the rafters whichproject beyond the bed-moulding, the mutules; and perhapsthe projection of the roof in front, to… … Fig. 120 AKCmTECTUEE. 91 their surface ; the absence of a base to the cokimn—as alco offillets between the flutings of the column, and the plainness ofthe capital. The trigljphs are to be so disposed that the widthof the metopes—the spaces between the triglyphs—shall beequal to their height.…
Carpentry · Architecture
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
