e n e and n d equal tone and n doXFig. 300, and draw d o and e Z, parallel to n c; also, through k,draw s g, parallel to n c; then, in the parallelograms, m s d o andg s el, find the elliptic curves, d m and e g, according to Art.118, and they will define the curves. The line, d e, being… … 344 AMERICAN HOUSE-CARPENTEJl.. 467.—To apply the mould to the plank. The mould obtainedaccording to the last article must be applied to both sides of theplankj as shown at Fig. 302. Before applying the mould, theedge, e/, must be bevilled according to the angle, c ^ ^, at Fig.300 ; if the rail is…
