Plastering, plain and decorative. A practical treatise on the art & craft of plastering and modelling, including full descriptions of the various tools, materials, processes, and appliances employed ... together with an account of historical plastering in England, Scotland, and Ireland, accompanied by numerous examples (1899)

Millar, William, d. 1904, Robinson, G. T · London : Batsford · leaf 300

An illustration from Plastering, plain and decorative. A practical treatise on the art & craft of plastering and modelling, including full descriptions of the various tools, materials, processes, and appliances employed ... together with an account of historical plastering in England, Scotland, and Ireland, accompanied by numerous examples, 1899, leaf 300
sepoints draw lines parallel to n 0 till they cut the raking lines in the points q, r, s, and then throughthe points/, </, r, trace the upper curve of the cyma-recta, and through the points ;-, s, n, trace thelower curve, thus forming the required raking cyma-recta. The curves may also be… … No. 46.—Raking Mouldings. used for describing the profile of the returned cyma-recta in the inclined cornice in an openpediment; also to return a raking moulding to a level moulding at the top. First draw ahorizontal line from the fillet as at p to o, at C, Fig. I on illustration No. 46, making the…

Plastering · Decoration and ornament, Architectural
