peed ratios being obtained by varying the diameters,precisely as with spur or bevel gears, the rules for the speed ratiobeing the same in both cases. Moreover, the various factors requiredin laying out and making such gears can be reduced to the simpletable shown. Such a table has been worked out… … 128 GEARING Example Let it be desired to construct a pair of spiral gears with 35 teeth inthe gear and 16 teeth in the pinion, using a 10 pitch cutter. Usingtable on page 126 we have Pitch diameter = 0.14143 X 35 = 4-95o. Outside diameter = 4.950 + 0.200 = 5.150. Pitch in inches to one turn of…
