Spur and bevel gearing; a treatise on the principles, dimensions, calculation, design and strength of spur and bevel gearing, together with chapters on special tooth forms and methods of cutting gear teeth (1914)
New York, The Industrial press; [etc., etc.] · leaf 235
case, shows that the large gear will be an internal bevelgear, such as shown in Fig. 16, this construction may be avoidedwithout changing the position of the shafts, the numbers of theteeth in the gear, the pitch of the teeth, or the width of face.This is done simply by subtracting the given center… … Fig. 16. Internal Bevel Gearing,a Type to be Avoided Fig. 17. Acute-angle Bevel Gearssubstituting Internal Gearing corresponding to those in Fig. 16 are shown in Fig. 17. It willbe seen that the contact takes place on the other side of the axisOP of the pinion. It is necessary to avoid internal…
Gearing
