ted. Draw the bisectinglines of the outer angles to cut the sides of the square in F and E;draw E F. A E F is the required triangle. Prob. 44. — To construct an isosceles triangle on a given base A B,and having a given vertical angle C With the angular point C as centre, and any radius, cut the…
