Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)

D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 426

An illustration from Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts, 1880, leaf 426 — rt). MILLS, GRAIN. For the various processes of milling, see Milling, Grain. See also Millstones.The present article relates to the construction and arrangement of grain-mills, and the various formsof mills employed. Milling with Stones.—Noyes Two-Run Mill, of which Fig. 3024 is a plan and Fig.… … revolutions per minute; B, main driving-shaft, 140 revolutions ; C, husk; D, upright smut machine,700 revolutions; E, cylinder bolt, 30 revolutions ; 1, pulleys driving stones, 140 revolutions ; 2, pul-leys driving upright shaft, 140 revolutions; 3, pulleys on spindles, 225 revolutions; 4, pulleys…

Mechanical engineering -- Dictionaries

Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
