Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)

D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 490

An illustration from Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts, 1880, leaf 490 — Machine.—Fig. 3213 is an example of the form of machine used formoulding the edges of carved work. The cutters are affixed to and revolve with the spindle shownat A, and the table is raised and lowered by the hand-wheel. Devices are provided to prevent thetable from turning and for the adjustment…

Mechanical engineering -- Dictionaries

Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
