Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor (1866)

Worthen, William Ezra, 1819-1897, [from old catalog] ed, Appleton, firm, publishers, New York. (1866. D. Appleton & co.) [from old catalog] · New York, D. Appleton and company · leaf 114

An illustration from Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor, 1866, leaf 114
GEOMETRICAL PROJECTION. 93 after being transferred to I L, to be turned over parallel to the horizontalplane ; this is expressed by simply drawing a circle of the diameter I^ L^;and producing the line a V to ci^; then set off the distance a^ e on eachside of the axis I K, and draw straight lines…

Mechanical drawing · Architectural drawing · Projection · Perspective
