MECHANICS. 225 … 16 226 MECHANICS. with a radius equal to the height at which the sliding block is in the link; where thisarc intersects that struck from the fore eccentric wdll indicate the point at which thesliding block will be when the gear is full forward, and the same arc described, cuttingthe arc from the…
