Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 353
Fig. 733. Fig. 734. C V, as 7 chain ; it must then enter properly and continue engaged with the chain-wheel.E is a chain-guide roller, that delivers the slack chain into the box or locker. 336 MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS. … Fig. 736. D is the chain-stripper, bolted also to the plate B, with a tongue or rib pro-jecting into the centre groove of the wheel which disengages the chain. Forms of chain-cables are rep-resented by the open circular link(Fig. 730), the open oval (Fig. 731),-TT- oval with pointed stud (Fig.…
Mechanical drawing
