ENGINEERING DRAWING. 509 … 510 ENGINEERING DRAWING. Fig. 1211 is a partial plan and elevation of a highway bridge built by theKing Bridge Company. It is pin connected, with floor-beams riveted to theposts above the pin. Fig. 1212 is a section, and Fig. 1213 the end post, withpart of the portal bracing. The lateral bracing of…
