surface of cir-culating coils include the lengthsof angles and all fittings; in thevertical radiators include the base.Figs. 1542 and 1543 are theend and side elevation of a radia-tor for live or exhaust steam, in-closed in a case for indirect heat-ing. Air is forced through thecase into the… … Fig. 1544.
