Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 109

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 109
104 STEAM POWER APPLIANCES. 247. FACTORY HEATING FROM … WASTE GASES. Coldair is blown through theannular chamber, betweenthe boiler and the chimney,by a fan, heated and dis-tributed for heating rooms.Additional draught maybe given to a chimney by ahigh-pressure blower andjet nozzle in the uptake.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
