Scale.—1-lGth inch = 1 foot.Longitudinal Section. Scale.—1-lCth inch =: 1 foot.Elevation and Transverse Section. Figs. 4:50, 451, and 452 represent the boilers of the Achilles steamer, constructed by Messrs. Caird dCo. This vessel plies between Liverpool and Glasgow, and is well known for her…
