ar transverse rocker-shaft I is arranged parallel to the shaft k. From each of theshafts k I an arm m extends upwards, and is jointed to a horizontal connecting-rod n. Each of theseshafts has also two other arms o o, or p p, extending from it, Fig. 916. To each of these last-men-tioned arms one of… … _ From the above it •will be seen, that -when the chain g is drawn forward, or in a direction towards theright-hand end of the main frame, each ring-rail will be raised upwards. So when the chain is sufferedto move backwards, the ring-rails will be left free to fall down by their own weight. The…
