Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 761
A A are the retort-mouths, the lids of which are fitted with stuffing-boxes, for the reason to be pre-sently described, and permanently jointed in their places with iron cement. BB are hoppers, capable of holding from 20 to 28 pounds of coal, which, when an air-tight slide-valve C is drawn back,… … E is the furnace, projecting beyond the face of the brickwork in which the retorts are set.F F are handles for working a piston contained in the mouth-piece A. Fig. 1911 is a transverse section of one half of a bench. The retorts Q, shown as circular, may bevaried in form if thought necessary. We…
Mechanical engineering
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
