Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 205
MACHINE, ROTARY. BRICK-MAKING MACHINE, ROTARY AND LOCOMOTIVE—By Joseph Grant. Fiis a plan of the machine. Fig. 609 is a side elevation, -with one of the propelling wheels removed. Fig. 610 is an end view of the mould-cylinder. Fig. 611 is a transverse vertical section of the machine, seen from the… … Fig. 613 is a view in detail of a grooved channel and cam, used in working the followers. The same letters of reference denote similar parts throughout the several figures. The nature of this invention consists in the use of two cylinders set horizontally in a suitable framingand revolving in…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
