11 an end view; and Fig. 1112 a plan of the entire machine. Figs. 1113 and 1114 are views of the hammers and cutting tool detached from the machine. Figs. 1115 and 1117, a sectional view and corresponding plan of the axis E, and its screw and nut. Figs. 1116 and 1118, detached views of the saddle… … The base of this machine, which simply rests, without being fixed, upon the dressed surface of themillstone A, consists of a narrow cast-iron plate B, also dressed on its under surface, and of sufiicientweight to retain it in the position in whicli it is set, without at the same time impairing its…
