Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 412
1 an end view; and Fig. 1112 a plan of the entire machine. Figs. 1113 and 1114 are views of the hammers and cutting tool detached from the machine. Figs. 1116 and 1117, a sectional view and corresponding plan of the axis E, and its screw and nut. Figs. 1116 and 1118, detached views of the saddle or… … The base of this machine, which simply rests, without being fixed, upon the dressed surface of themillstone A, consists of a narrow cast-iron plate B, also dressed on its under surface, and of sufficientweight to retain it in the position in which it is set, without at the same time impairing its…
Mechanical engineering
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
