Scale.—1£ inch:=l foot. s, the steam-pipe from the boiler. It is furnished with two valves ; one of them c, is the throttlevalve; the other d, is the cut-off valve; the latter is worked by a cam fixed on the crank-shaft, whicliworks the lever e, the fulcrum of which is fixed on the timbers of the…
