Fig. 1737.—Elevation of a section.B B, the balance tanks. C, the keel block. D D, cross beams supporting the chock blocks E,E E, the chock blocks. F F, the outside truss girders.ff, the inside standards of the main framing to guide the balance tanks B.*F Beam securing the standards. G G, the… … a u U &BEf II, the stationary spuds for working the tanks. J J, pinions working in the racks on the spuds.K lv K, outline of a vessel in the dock, supported by the side supports L L, the chock blocks E E thiseel block C, and the balance tanks B B.L L, the side supports run up and down by the…
