Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 802
face of the cogs, as described. And lastly, Making that part of the guide-bar which rests against the guide-plate to determine theform of the face of the cogs separate from, and movable on, the guide-bar, and properly bevelled torelieve and clear the cutter for its back movement, substantially as… … inches face. This is a heavy and strong-built machine, adapted to cutting spiral spur and bevel geerswithout any additional fixtures. M is the spindle to which the geers are fastened when being cut, and to which is attached the dial 800 GEER-CUTTING ENGINE. plate B, on the upper surface of which…
