Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)

D. Appleton and Company · New York : D. Appleton and Co. · leaf 196

An illustration from Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes, 1873, leaf 196 — Fig. 2617. c, planing-head for planing between trunnions. It, tool-holder. Fig. 2522. Standing-head. b, feed-geer, (same in Fig. 2519.) g, handle for changing feed-geer. LATHE. 191 … lUi LATUE. 11 ■^i

Mechanical engineering · Mechanics · Engineering

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
