Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 203
a quicker motion be required, as when the action of the tool is near the axis of the maehiuf,the shaft E is thrown out of geer, (as shown in the views, Figs. 2512 aud 2543.) and the shaft D is movedendways until the wheel e and pinion / upon it geer respectively with the wheel d u]xin the… … LATHE. 190 and indeej tlie liighest, is obtained by arranging the gcering of the machine as it is represented in theengravings. Tlie shafts D and E, it will be observed, are both out of gcer, (being retained in thaiposition by the catches k k,) and the wheel 6 upon the cone-spindle C is in geer…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
