the charge E. A reciprocating movement being imparted to the charger, the aperture in the same, in passing backand fortli under the outlet of the magazine, will receive the charge of composition for a cap and will dis-cliarge the same as the charger is drawn back into a cap brought immediately… … raTchet-wheel A and to the charger E by means of the vibrating lever C, suspended by and vibratingon the arm G projecting from the end of the machine, the cam B on the main-shaft, tlie cord t con-nected to the upper end of C and passing to tlie rear over a loose pulley on the axle S, and…
