Blessing, George F. (George Frederick), 1875-1921, Darling, Lewis A. (Lewis Andrew) · New York, J. Wiley & sons; [etc., etc.] · leaf 109
representing a bearing. Note that the distancebetween bearings is given from the center line of one to thecenter line of the other. 3. Method of representing the broken end of a timber viewedfrom the side, also method of showing cross section of timber. Group B shows the following conventions: I.… … ®.
Mechanical drawing
