ed to the groove in the rim of said table. Said yoke/has a vertical shot formed throughit, the longitudinal centre of which is in continuation of a right lane extending horizontally outwardsfrom the centre of the axis c. By means of a stud 23 which extends upwards in a perpendicular… … to the right or left hand, it communicates a corresponding movement to said yoke. The lever or 1°connected by a vertical axis 24 to the fixed frame, as is shown also at 24 in Figs. 3063 and 3064: ithas a broad part in which is a slot or opening of sufficient dimensions to allow the sliaft c to pass…
