Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 612
t for the larger spindle is differently constructed, as will be observed from the face view of itgiven in Fig. 3287. This consists of a strong plate \V, annularly recessed to receive a ring X, flushwith its exterior surface. The ring X has a portion of its circumference cut into teeth to geer with… … will be correspondingly affected, and will, by its motion, change the relation of the cutters fff, in re-spect of tlie axis of the chuck. For this purpose, three spiral recesses ffr/ff are formed on the interiorcircumference of the ring, into which the exterior ends of the cutters project and abut…
Mechanical engineering · Mechanics · Engineering
