ure in the charge E. A reciprocating movement being imparted to the charger, the aperture in the same, in passing bachand forth under the outlet of the magazine, will receive the charge of composition for a cap and will dis-charge the same as the charger is drawn back into a cap brought immediately… … ratchet-wheel A and to the charger E by means of the vibrating lever C, suspended by and vibratingon the arm (V projecting from the end of the machine, the cam 1> on the main-shaft, the cord t con-nected to the upper end of C and passing to the rear over a loose pulley on the axle S, and…
