ight of the partition F, and between itand the beater. The object of the upper conic frustum is to prevent the blanks from being carriedaround towards the beater in too great a body; it also facilitates the downward movements of theDlanks towards the space E. The triangular plates or arms of the… … 3243. The next part of the apparatus is that by which the blanks are regularly delivered or fed from thecircular space E. It consists of a horizontal slide-plate b, Fig. 3243, (which represents a view of theunder sides of the hopper and lower conic frustum D,) affixed to the lower edge of the…
