Fig. 3371 is a longitudinal section of one of the lower or feeding and delivering rollers, and of one otthe driving pinions. Fig. 3372 a front elevation of the three driving pinions, corresponding in position with their respec-tive rollers, as shown in Fig. 3370. I i . 3373 a detached view of one…
