Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 135

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 135
463. LINK OR CONNECTINGROD, with adjustable brasses. Keysinside and outside of pins. 463a. STAKE PULLER. — Aneasy way to pull stakes and posts. Aclevis to pinch the stake or post againstthe end of the lever with the leverpivoted to the foot post. 463&. STALK PUL-LER. — The conicalspiked drums… … 463^. VALVEGEAR FOR EX-PLOSIVE MO-TORS.—H, air inlet;F, air valve; G, gasor gasoline valve; f,air valve lever; B, gasvalve lever operatedfrom the cam at C;O, exhaust; E, ex-haust valve; e, ex-haust valve lever, op-erated by cams at c.
