Appleton's dictionary of machines, mechanics, engine-work, and engineering (1869)

New York, Appleton · leaf 897

An illustration from Appleton's dictionary of machines, mechanics, engine-work, and engineering, 1869, leaf 897
an eddy in the interior of a cylinder, the effects of the centrifugal force show themselves differently^cording to the different inclinations of the projections or orifices made on the circumference hi Fig. 3819 the orifices are disposed in the direction in which the centrifugal force can least…

Mechanical engineering

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
