Brown, Harold Haven, 1869-1932 · Chicago, Atkinson, Mentzer & company · leaf 189
I i ; i I … THE ARRANGEMENT OF VIEWS IN WORKINGDRAWINGS OF TYPICAL OBJECTS- 180 WORKING DRAWINGS 181 A sketch presents the general appearance of an object. Aworking drawing gives accurately all the facts regarding theshape, sizes and construction, so that from it a workman canbuild the box, the chair, the…
Drawing · Decoration and ornament
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
