u „5> i>°..<*t ..VKG <SVaJ.jr</& Y … XIII.A WINDOW FOR A FRAME HOUSE. Charts XIX-XX-XXI-XXIL Figs. 103-104-105-106. The specific problem in this instance is to constructthe Elevation or rather Elevations, One-half Interiorand One-half Exterior of a Window in the wall of aFrame House. A—A represents the elevations required and B andC…
