Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings (1895)

Freitag, Joseph Kendall · New York, J. Wiley & sons; [etc., etc.] · leaf 130

An illustration from Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings, 1895, leaf 130 — mentioned figure, by means of the top and bottom tie-plates shown. Fig. 64 shows a section at the bottom of a bay windowin the Masonic Temple. Fig. 65 shows a half plan of the metal framing for theState Street bay window in the Reliance Building. … 112 ARCHITECTURAL ENGINEERING. The terra-cotta mullions of the bay and the pier areshown in plan in Fig. 66. The column bracket in the bay is given in Fig. 67, whileFig. 68 is a section at the side, bracket. The method of supporting the floors and ceilings in thebays is shown in Fig. 69. *3 6 —k-I…

Building, Iron and steel

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
