Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings (1895)

Freitag, Joseph Kendall · New York, J. Wiley & sons; [etc., etc.] · leaf 86

An illustration from Architectural engineering. With special reference to high building construction, including many examples of Chicago office buildings, 1895, leaf 86 — p the maximum resistance with the leastweight, must also be determined by repeated tests. The different character of the metal-work in combina-tion with the concrete, presents three varieties: floorsusing curved I beams, those using steel straps, and thoseusing wires. 1. Curved I Beams.—This… … Fig. 33.

Building, Iron and steel
