Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 149
oncrete pile i^iers is illustrated in Plate 8.This type of trestle has been found to be rela-tively inexpensive, and seems likely to be veryextensively used. The following description re-fers to the trestles of this kind built by the Chi-cago, Burlington & Quincy Railroad: The spans are 14, 15,… … Fig. 54. Cross-Section of Concrete Pile Trestle Showing Details ofBent. See Plate 8. the girder slabs which form the floor, each span con-sisting of two slabs placed side by side. The concrete piles are of two forms: (1) rectangularcast piles; (2) Chenoweth rolled piles. The cast ormoulded…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
