Gilroy, Clinton G · New York, G. D. Baldwin · leaf 384
it is keyed, or made fast, onthe end of the cam shaft G; and it is by means of this shaft, inconnexion with suitable tappets and levers, that motion is commu-nicated to the headles for the purpose of shedding the warp, as wellae for giving motion to the shuttle. The cranks of the driving shaftare… … weighted in the ordinary manner used for coarse goods, namely, bypassing a rope round the circumference of each end, to which ropea fi-iction weight M, is attached. The cloth roller and take-up motion(as any practical manufacturer will perceive) possess no feature ofnovelty, consisting merely of a…
Weaving
