Gilroy, Clinton G · New York, G. D. Baldwin · leaf 480
coarse weft, to put in one pick, prior to the Jacquardshedding^ and one return pick of the same weft after the Jac-quard shedding^ when the bowl 7, will immediately ascend, andallow the shuttle boxes m, m^ to descend by their own gravity ;and thus the upper shuttle is enabled to put in two picks of… … The third feature of the improvement comes into Operation, inOrder to complete the weaving, or to put in the quiltlng, or stitch-ing threads^ hy shedding the colonred warps h\ and h^;—this isaccomphshed by an improved method of hfting and lowering the.griflf of the Jacquard machine, in order to…
Weaving
