The art of weaving, by hand and by power, : with an introductory account of its rise and progress in ancient and modern times. For the use of manufacturers and others. (1844)
Gilroy, Clinton G · New York: : George D. Baldwin · leaf 367
sition of one end of this leather strap, as bolted to the horizontalshaft U, will be seen at Y, in both Figs. The shaft U, has suitablebearings at each end, which are indicated by the dotted lines in Fig.155, and at Z, Fig. 156. The protector A2, as seen in both theseFigs, is of the ordinary… … PLAIN WEAVING. 349 Figs. 157,158, 159 and 160, show the different parts of a loom,as improved by Messrs. Apelles Howard, of Stockport, and JohnScattergood, of Manchester. Fig. 157 is a back view of the common loom; Fig. 158, a sideview, in which part of the framing is removed for the purpose…
Weaving
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
