Fairbairn, William, Sir, 1789-1874 · London, Longman, Green, Longman, Roberts & Green · leaf 146
Fig. 254 is a transverse section of the entire mill, in whichare shown the garners for undressed and dressed wheat, themechanism by which it is cleaned and conveyed from theformer into the latter, the sack teagle, &c. ON IRON BUILDINGS FOR CORN MILLS. 121 Fig. 254. … Fig. 255 is a plan of the first floor, corresponding* with theplan, fig. 253, the line of section being taken through the firststory of the mill. The house in which this mill is contained consists of an assem-blage of plates of sheet iron, A, A, A, of a suitable thickness, conso-lidated and bound…
Mills and mill-work · Machinery
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
